Vitocal 300-A

Environmentally Responsible Heat Pumps – Find out more about the different options and benefits!

Rated heating power

13.2 - 55.8 kW

High heating power

With two-stage operation

A cascade of five devices is possible

Power up to 279 kW

Low operating costs

Thanks to high efficiency

Low noise and vibration

Thanks to the sound-optimal design of the device

Flow temperature

Up to 64 °C (AWO 302.B60), up to 55 °C (AWO 302.B25/B40)

Good partial load performance

Thanks to the two-stage design

Effective defrosting

By reversing the refrigerant circuit

Easy-to-use Vitotronic control unit

With plain text and graphic display

Remote control and remote monitoring

Provides connection to Vitocom 100 and Vitocom 300

Vitocal 300-A is a high-efficiency heat pump with an air heat source of up to 47.2 kW

Viessmann’s Vitocal 300-A is an air-source heat pump with a power range of 13.2 to 55.8 kW. Up to 279 kW of power is possible with up to five Vitocal 300-A heat pumps cascading.

With a high efficiency of up to 4.3 (A7/W35), the outdoor heat pump meets the requirements of convenient heat supply in offices or commercial buildings. Even with an outdoor temperature of -22°C, this unit reaches a flow temperature of up to 64°C.

Two output stages ensure the efficiency of the Vitocal 300-A. Experience shows that about 70 percent of the annual heat load can be covered under partial load conditions. This means that the heat pump works with only one compressor, which allows the highest COP values to be achieved.

Integrated range of solutions for Vitocal 300-A

Benefit from value-added and digital services from Viessmann's integrated range of solutions.

Viessmann Heat

Viessmann Wärme is our heating system rental service - ideal for those who want to enjoy superb heating comfort without having to buy a boiler.

ViShare

Smart electricity tariffs for your home. Flexible, environmentally friendly and 100% renewable. The electricity tariffs are set by Energy Market Solutions GmbH (EMS), a contractual partner of the ViShare Energy Community and a subsidiary of the Viessmann Group.

Funding professional

The Viessmann FörderProfi service streamlines and simplifies the entire subsidy process, from application to payment.

The ViCare app

The ViCare app provides intuitive heating control. Green for go - the user can see at a glance in the app whether their heating system is working as it should.

The ViGuide app

ViGuide is an application for sales partners. It has numerous functions for monitoring and managing systems in both detached and multi-family houses, as well as providing quick access to the technical service.

Vitoconnect

Vitoconnect is the interface between the boiler and the app - a prerequisite for controlling the heating system via smartphone and tablet. It also enables remote system maintenance for contractors via the Vitoguide app.

wibutler

wibutler is a manufacturer-independent smart home control centre that connects products from different manufacturers and enables their control and automation through apps.

More about Vibutler

Convenient management

The Vitotronic 200 (WO1C) is wall-mounted inside the building, making it easy to commission and operate the heat pump. In a dual-mode system, such as in combination with a gas or oil boiler, the heat pump control unit can automatically start a second heat generator.

In addition, the Vitotronic 200 heat pump control unit is able to communicate and, via the Vitocom 100 or Vitocom 300 communication module, allows you to configure, monitor and optimize the heat pump system via the Internet using the Vitotrol app on your smartphone or tablet.

If Vitocal 300-A is used in commercial applications, it can also be connected to a building management system using Vitogate 200 KNX.

Product details

Rated heat output (kW)	10.9 – 47.2 kW
COP in heating mode	Up to 4.3 (air 7 °C/water 35 °C)
Energy efficiency class	AWO 302.B25/B40: A++ / A+, AWO 302.B60: A+ / A+ Energy efficiency class according to Commission Delegated Regulation (EU) No 811/2013 for heating, medium climatic conditions – low temperature application (35 °C) / medium temperature application (55 °C)
Applications	Large residential buildings, commercial enterprises, local government premises, new construction and modernization projects.
Surgery	Vitotronic 200 wall-mounted control unit with text and graphic display, can be operated via the ViCare app
Hot water heating	An additional DHW cylinder is required, which provides a high level of DHW convenience.
Additional features	If Vitocal 300-A is used in commercial applications, it can be connected to a building management system using Vitogate 200 KNX.
Product cross-section

Product details

Rated heat output (kW)	10.9 – 47.2 kW
COP in heating mode	Up to 4.3 (air 7 °C/water 35 °C)
Energy efficiency class	AWO 302.B25/B40: A++ / A+, AWO 302.B60: A+ / A+ Energy efficiency class according to Commission Delegated Regulation (EU) No 811/2013 for heating, medium climatic conditions – low temperature application (35 °C) / medium temperature application (55 °C)
Applications	Large residential buildings, commercial enterprises, local government premises, new construction and modernization projects.
Surgery	Vitotronic 200 wall-mounted control unit with text and graphic display, can be operated via the ViCare app
Hot water heating	An additional DHW cylinder is required, which provides a high level of DHW convenience
Additional features	If Vitocal 300-A is used in commercial applications, it can be connected to a building management system using Vitogate 200 KNX.

ServiceConnect Commercial

The innovative service concept gives Viessmann’s sales partners an additional advantage when working with commercial customers and local authorities thanks to complete service from a distance.
