Biomass boiler
Cost-effective wood pellet boiler for all-round performance
-
Rated heat output: 20 - 47 kW
-
Energy-saving ceramic glow ignition system
-
Perfect replacement for an old oil boiler
-
4.3-inch touchscreen for easy operation
Find your local installer for one-on-one advice with the Channel Partner Locator.
Efficiency
Up to 91.4%
High combustion quality
Burner design ensures high combustion quality and low dust
Large pellet hopper
Optimized for bag charging
Convenient management
4.3-inch touchscreen for easy operation
Energy efficiency class
20 - 47 kW: A+
Economical wood pellet boiler for versatile operation
The current debate around energy comes amid a huge interest in renewable fuel-based heating systems. Moving away from fossil fuels is more relevant than ever. Biomass systems are in particular demand, not only as a climate protection measure, but also because the fuels themselves are readily available locally.
The Vitoligno 100-C from Viessmann represents an affordable solution for this sector. With a capacity of 20, 25, 35 and 47 kilowatts, it is an easy-to-operate wood pellet boiler. It does not require a buffer tank for heating water to work – it works directly from the system. The power of the Vitoligno 100-C ceramic ignition system is an economical 270 watts.
Features of the Vitoligno 100-C
This boiler is a versatile performer, it can be quickly charged by hand and easy to clean. With an efficiency of up to 92 percent, all power stages comply with energy efficiency class A+. Proven burner design ensures high combustion quality and low dust content (9 to 14 mg/Nm3) at 13% Oâ â depending on size, power and load condition.
Single-stage combustion air (primary air) is supplied from the bottom of the pot; secondary air – from the side wall. Combustion chamber temperature sensor and differential pressure sensor ensure optimal air supply. The sensor compensates for any fluctuations in the calorific value of the fuel. The ash box only needs to be emptied when it is time to replenish the hopper with wood pellets.
In addition to weather compensation control and a 4.3-inch touchscreen for easy operation, 2 heating circuits with mixer, DHW heating and buffer operation are included as standard. Two auxiliary modules allow you to connect additional heating circuits, each of which is equipped with a buffer tank for water heating and another tank for hot water. It is possible to integrate other (existing) heat generators, as well as connect a district heating pipe.
The Vitoligno 100-C is designed mainly for bagged loading. Wood pellets are usually sold in convenient bags. However, as an option, the blind lid on the pellet hopper can be replaced by a stand-alone vacuum supply system. To do this, it is necessary to install a cyclone separator with pneumatic separation.
The combination with the Viessmann Vitocal heat pump creates a hybrid heating system that helps to further reduce energy costs. The energy required to create a baseload is obtained from free green energy (air, sun, water, earth), and electricity is only required to drive the pumps. If this heat is not enough in winter, the Vitoligno 100-C is also launched, which means that the Vitocal heat pump is also suitable for installation in older buildings with a high thermal load as part of a retrofit project.
Vitoligno 100-C: an impressive performer
- Biomass boiler for carbon-neutral combustion using wood pellets
- Independence through the use of renewable energy sources, Local fuels
- 4.3-inch touchscreen for easy operation
- Can be combined with other (existing) heat generators (heat pump, solar thermal system, oil/gas boiler)
- Large pellet hopper (230/255 l) optimised for bag loading
- The old oil boiler can be easily replaced
Product details
| Exit |
20 – 47 kW, output stages in kW: 20 | 25 | 35 | 47 |
|---|---|
| Allowable Flow Temperature |
100 °C |
| Allowable operating pressure |
3 bars |
| Efficiency |
Up to 91.4% |
| Energy efficiency class |
20 – 47 kW: A+ |
| Fuel |
Wood pellets |
| Applications |
Detached houses, semi-detached houses, new construction and modernization projects |
| Surgery |
Simple and intuitive operation via 4.3-inch touchscreen |
| Hot water heating |
Integrated Cylinder |
| Additional features |
In addition to weather-compensated controls and a 4.3-inch touchscreen for easy operation, 2 heating circuits with faucet, DHW heating and buffer mode are included as standard. |
| Product cross-section |
|
